AUTORUN electric actuator for butterfly valve is light weight and large torque. 380V/220V/110V AC or 24V/110V DC power or other power according to customer requirements as options. 90°rotary can open and close butterfly valve perfectly.

Features

• Visual valve position indicator

• Manual override for emergency operation

• OHQ series is explosion-proof (Ex d IIC T5 Gb)

• Quarter turn (90°) rotation or 110°~270° customized

• Mechanical traval stops

• ISO 5211 mounting pattern for butterfly valve

• Female double square or round with keyslot output drive

• Heavy duty motor with overload protection

• Self-lock function prevents inversion and insure stability and reliability

• High cycle life with low friction bearings on all moving and sliding surfaces

• Cover with anodize treatment and polyester powder coating for corrosion resistance

Specifications

Motion Range: 0-90°

Torque Range: ODL: 30-2000Nm OHQ: 50-2000Nm

Ambient Temp.: -30º C~+60º C

Open/Close Time: ODL: 5S-40S OHQ: 8S-112S

Actuator Body: Aluminium Alloy

Protection Class: IP67,IP68

Type: On-off, Modulating (Regulating), Passive Contact

Available Valve Size: Butterfly Valve (DN25-DN400)

Why choose us?

1. We are factory, we have the advantage of price, technical and OEM service.

2. We are an intelligent company, We have OA system, ERP system, that can help us to management, control quality efficiently.

3. Strictly consistent with original standard, we don’t change quality to reduce cost.

4. We focus in comprehensive product lines design improvement, which devote ourselves to develop world class products. The commitment we make to our customers of all sizes, will reflects in the quality and service.

5. Expert sale, technical and after sale team to offer you the instant reply.

6. We attend oversea exhibition every year. Meanwhile, we visit our customer to know and inform our customer’s the new products, market direction. We solve customer’s problem in time.

7. We evaluate the quality activities of the departments based on customers' assessment and quality cost so as to improve weaknesses of the quality control activities and systems.

8. Universal fit, off-the-shelf components, modern materials and component substitution recommendations give from Autorun help you explore cost and part savings!

We specialize in Dcl-10 Quarter Turn Modulating Electric Actuator for Butterfly Valve, Metal/Resillient Seat, Ce/CSA/RoHS, Watertight IP68, Ship/Offshore/Marine/HAVC, Controller production and have many years of experience in sales and service of related products so that we can serve customers well and respond quickly to customer needs. In the past development, we have achieved impressive outcomes, and the scale of the company is growing. Now our products sold and served at more than 15 countries around the world.
